Type

Function

Bluetooth V2.1
SPP, Class 1

- Bluetooth V2.1 Serial port profile
- Class 1: 100 meters
- Model: BT-232B (Internal chip antenna), the same distance and
function as BT-232B-E
- Model: BT-232B -E (External dipole antenna)


Bluetooth V4.x BLE Serial converter

- Baud Rate:
1.2/2.4/4.8/9.6/19.2/38.4/57.6/115.2/230.4/460.8/921.6 Kbps
- Parity: none/even/odd
- Stop bit: 1/1.5/2
- Data bit: 7/8
- Support iOS, Android
- Two-way data communication
- RS-232 (Model: BLE-232 B/C)
- RS-422/485, Support RS-485 Modbus RTU (Model: BLE-48 5C)


Beacon reader

- Scan the BLE beacon and report the packet to serial port
- Option Beacon format: RTLS, ALL BLE beacon
- RS-232 (Model: BLE-232 B/C -R)
- RS-422/485, (Model: BLE-485C-R)


1-N Broadcast

- 1-N Broadcast w/o paired
- Any data from each node will broadcast to the other nodes
- RS-232 (Model: BLE-232 B/C -N)
- RS-422/485, (Model: BLE-485 C -N)

Mesh

- Support mesh network
- RS-232 (Model: BLE-232 B/C -M)
- RS-422/485, (Model: BLE-485 C -M)


	BLE Module

- BLE single mode module

- Model BLEM-S: Serial converter

- Model BLEM-R: Active RFID or Beacon reader
- Model BLEM-T: Active RFID or Beacon tag


		Dual mode

- Support Bluetooth V2.1 and V4.2 BLE
- RS-232 (Model: BTD-232)
- RS-422/485, (Model: BTD-485)

Bluetooth product selection guide:

Bluetooth V2.x, V4.x, V5.x
